Product Features

• Autoscan
• Supplied with PSU
• 6.3 mm output for mixed signal
• 482 mm (19″) rack installation, 1 RS
• XLR output for each channel, bal
• True diversity system with removable antennas (BNC connection)
• Volume & squelch controls for each channel
• LCD for group/channel, antenna A/B, RF receiving level, AF audio level and additional LED level display
• ACT function for transmitting frequencies to transmitters TXS-606LT or TXS-606HT via infrared signal
• 1,000 selectable UHF frequencies (672.000-696.975 MHz) for each channel (10 groups, 100 frequencies each)

Product Specifications

• THD: < 0.5 %
• Weight: 1.8 kg
• Dynamic Range: 120 dB
• RF S/N Ratio: 105 dB
• Admiss. Ambient Temp: 0 – 40 °C
• Carrier Frequency: 672.000-696.975 MHz
• Audio Frequency Range: 30-18,000 Hz
• Power Supply: Via supplied plug-in PSU
• Dimensions: 482mm W x 45mm H x 195 mm D
• Audio Output: 350 mV/600 Ω (Jack) 25 mV/600 Ω (XLR, bal.)
