The Trantec S2.4–HBX is a dual channel 2.4GHz ISM Digital Microphone Wireless System, with up to 16 selectable channels to choose from. It includes one Trantec S2.4-HDX Handheld Microphone, one Trantec S2.4-BTX Beltpack Transmitter and one S2.4-RX2 Dual Receiver with LCD display.

The transmission distance is up to 30m in optimal conditions. The S2.4-RX2 receiver features two balanced XLR outputs, or a single mixed 6.3mm output. Connection leads are not included but are available via the links at the bottom of the page.

Product Specifications

Receiver

• Band Range: 2MHz
• Power Supply: DC17V
• Dynamic Range: 85dB
• Available Channels: 16
• Power Consumption: 2W
• Signal–to–Noise Ratio: >95dB
• Total Harmonic Distortion: <0.1%
• Carrier Frequency: 2.404-2.474GHz

Handheld Transmitter

• Ultraharmonics: <20dB
• Modulation Type: GFSK
• Battery Life: Approx. 5 hours
• Power Supply: 2 x 1.5V AA batteries

Beltpack Transmitter

• Ultraharmonics: <20dB
• Modulation System: GFSK
• Battery Life: Approx. 5 hours
• Power Supply: 2 x AA batteries
