Chord UP2-BR UHF Wireless Beltpack Receiver & Earphones


This product has been discontinued, but we can recommend compatible replacement parts.

The Chord UP2BR is a selectable channel UHF Wireless Beltpack Receiver & Earphones, operating on UK licence free frequencies (863.25MHz or 864.75MHz). The receiver unit can be connected to any line input for regular wireless microphone operation or as a wireless link to an active speaker.

Frequency is switchable on the UP2-BR Receiver which allows you to use two systems independently of one another in the same area, or to allow users to switch between two different transmissions. Unlimited UP2-BR Receivers may be used in unison with 1 or 2 UP2-BT Beltpacks or UP2-HT Handhelds for any application that requires multi-listeners, such as: guided tours, interpreted presentations or a silent disco.

The unit comes with a set of over-ear headphones, a 4-pole 3.5mm lead and 2 x AA batteries so you’ll be ready to get set up straight out of the box.


  • Headphone Power: 2 x 50mW @ 1kHz
  • Carrier Frequencies: 863.25 MHz + 864.75 MHz
  • Power Supply: 3Vdc (2 x AA batteries included)
  • Controls: Off-Ch1-Ch2 slide switch, Output level rotary
  • Headphone Connector: AF out 3.5mm (stereo summed to mono)
  • Line Output: 3.5mm 4-pole (input to smartphone via headphone jack)
